36V 360W Switching power supply

Short Description:


Product Detail

Detail

Product Tags

Features

Switching Power Supply

1. AC input range ,constant DC output

2. Protections: Short circuit / Overload / Over voltage / Over temperature

3. 100% full load burn-in test

4. Low cost, high reliability, good performance.

5. Widely used in Switch, industrial automation, led lighting, device, etc.

6. 24 months warranty

Specifications

DC Output

DC Voltage: 36V

DC Current : 10A

Output power: 360W

Ripple & Noise: 240mvp-p

DC Adjustable Range: ±10% Rated Voltage

Voltage Tolerance: ±2.0%

Line Regulation: ±0.5%

Load Regulation: ±1%

Setup,Rise Time,Hold Up Time:200ms,50ms, 20ms/230VAC

AC Input

AC Voltage Range: 85-264VAC

Frequency Range: 47-63Hz

Efficiency:>86%

AC Current: 0.86/115V 0.4A/230V

AC Inrush Current: 20A/115V 40A/230V

Leakage Current< 0.5mA /240VAC

Protection

Over-load: 105%-150% hiccup mode,Auto-recovery

Over-voltage: 115%-135% Cut Off the Output,Auto-recovery

Over-temp. : Shut down O/P voltage, Auto-recovery

Environment

Working temp.: -10~ +60C° (Refer to output load derating curve)

Working Humidity:20 ~ 90% RH, non-condensing

Storage Temp.: -10~ +60C°

Storage Humidity: 10 ~ 95% RH

Safety

Isolation Resistance:I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC / 25C°/ 70% RH

Withstand Voltage: I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Safety standards: CE,RoHS,FCC,ISO9001

Size

215*115*50mm

Weight

0.82kg/pc

Warranty

2 years
