52V 600W Switching power supply

Short Description:


Product Detail

Detail

Product Tags

Features

Switching Power Supply

1. AC input range ,constant DC output

2. Protections: Short circuit / Overload / Over voltage / Over temperature

3. 100% full load burn-in test

4. Low cost, high reliability, good performance.

5. Widely used in Switch, industrial automation, led lighting, device, etc.

6. 24 months warranty

Specifications

Model

Specification

S-600-36

S-600-12

S-600-15

S-600-24

S-600-52

DC Output voltage

36v

12V

15V

24V

52V

Output voltage range(Note:2)

±2%

±1%

±1%

±1%

±1%

Rated output current

16A

50A

40A

25A

11.5A

Output voltage range DC

33~40v

10.5~13.2V

13.5~16.5V

22.5~27V

46~58V

Wave and noise(Note:3)

75mVp-p

120mVp-p

150mVp-p

240mVp-p

300mVp-p

Inlet stability(Note:4)

±0.5%

±1%

±1%

±1%

±1%

Load stability(Note:5)

±1%

±0.5%

±0.5%

±0.5%

±0.5%

DC output power

600W

600W

600W

600W

600W

Efficiency

86%

83%

84%

86%

89%

AC input voltage range

100-132VAC/190-240VAC selected by switch 47-63Hz

Input current

5A/230V

Power factor

0.65 - 0.75

AC Inrush current

46A/230V

Leakage current

<3.5mA/240VAC

Overload protection

120%-150% Reset: auto recovery

Over-voltage protection

120%-150%

High-temperature protection

ERH3≥65°C~70°CFan on, ≤55°C~60°CFan off, ≥80°C~85°C, Cut off output (5-15V)~(24-48V)

Temperature coefficient

±0.03%/°C(0~50°C)

Setup, rise, hold up time

1s, 100ms, 50ms

Vibration

10~500Hz, 2G 10min,/1 cycle. Period for 60min, Each axes

Withstand voltage

I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Isolation resistance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC

Working temperature and humidity

-10°C~+60°C, 10%~95%RH

Store temperature and humidity

-20°C~+85°C, 10%~95%RH

Overall dimension

215*115*50mm (L*W*H)

Weight

0.96Kgs
