Full Gigabit Poe Switch 16 ports + 2 Gigabit RJ45 + 2 Gigabit SFP Managed

Short Description:

This PoE Switch is a green energy efficient all gigabit Ethernet switch product with rich features, which is widely used in hotels, hospitals,school,Internet cafes, company,and other applications.On the basis of high performance access,each port provides 30W PoE power supply capability, and provides a comprehensive security access strategy, which is easy to use and is the ideal choice for gigabit access.


Product Detail

Product Tags

Features

Switching Switches

• 16 ports 10/100/1000Mbps POE + 2 RJ45+2 SFP.

• 250m Distance;Vlan support

• Support IEEE802.3AF/AT

• Whole Power:250W(52V 4.8A)

• All port supported by MDI/MDIX auto flip and self negotiation

• Supply 18 10/100/1000Mpbs adaptive high speed forwarding data packet non-lost port.

• Support IEEE802.3x flow control for Full-duplex mode and backpressure for Half-duplex mode.

• Each port max. power supply reached 30W.

Specifications

Product

16+2+1 port 250m POE switch(Built-in)

Model No. Hi-F1621GBL-C
PoE Port 1 to 16 port support IEEE802.3af/at
UP link port 17th-18th port support 1000Mbps
PoE output 15.4W/30W    IEEE802.3af/at
PoE whole power ≤250W
PoE type End-span
Power distance ≤250m
Network Standard IEEE 802.3, IEEE802.3u,802.3x,802.3af/at
Network Medium 100/1000BASE-TX: 5 class and above non shielded twisted pair
Data Distance ≤250m
Switch capability 12Gbps
Forwarding Mode Store and forward
Forwarding Rate 100Mbps:14880pps1000Mbps:14800pps

1000BASE-T: 1488095pps/port

MAC Address 2K MAC address table
Port function Power priority mechanism, fast and forward, MAC automatic learning and agingIEEE802.3X Full-duplex and mode and backpressure for Half-duplex mode
Indicator LINK/ACT. 100Mbps;POE Status indicator;   POWER indicator;EXTENDER indicator
Working Environment Working Temperature: -10°-- 55°C
Input power AC100-240V 50/60HZ
Weight 2.1kg
Size 270mm*180mm*44mm(L*W*H)

LED Indicators

Power LEDThe Power LED lights up when the switch is connected to a power source.

Link/Act LED:

Stable Green : Indicates that the port link succeeded.

BlinkingIndicates that the switch is either sending or receiving data to the port.

Light off: No link.

PoE LED:

GreenIndicates the PoE powered device (PD) is connected and the port supplies power successfully.

Light offIndicates no powered device (PD) connected

Applications
