DC Switching Power Supply 72W 12V 6A

Short Description:


Product Detail

Product Tags

Features

72W power supply

● Widely used in Switch, industrial automation, stepper machine,device, etc.

● Universal AC input / Full range.

● High efficieney

● Protections. Short circuit / Overload /Over voltage / Overload

● 100% full load burn-in test

● 2 years warranty

Specifications

Model No.

HSJ-72-12

HSJ-72-24

Output

DC Voltage

12V

24V

Current Range

0~6A

0~3A

Power

72W

Ripple And Noise

Max 240mVp-p

Voltage ADJ.Range

10~13V

22~26V

Voltage Tolerance

±5%

Setup, Rise Time

1500ms, 30ms / 230VAC

Input

Voltage Range

90~260VAC

Frequency Range

50~60Hz

Efficiency

>0.85

PF

0.6

Current

7A/110VAC, 4A/220VAC

Surge Current

40A/110VAC, 60A/220VAC

Leakage Current

Max 3.5mA/240VAC

Protection

Overload

Above 110%-150% of rated power

Shut-down output voltage, auto recovery after fault condition is removed

Overvoltage

Above Max. Voltage (105% of rated voltage)

Shut-down output voltage, auto recovery after fault condition is removed

Over temperature

90℃ ± 5℃(5~12V)  80℃ ± 5℃(24V)

Shut-down output voltage, auto recovery after fault condition is removed

Environment

Working Temp. & humidity

"-20°C~+60°C,  20%~90%RH

Storage Temp. & humidity

"-40°C~+85°C,  10%~95%RH

Safety

Withstand Voltage

I/P-O/P: 1.5KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min;

Safety

GB4943 ;IEC60950-1; EN60950-1

EMC

EN55032:2015/AC:2016; EN61000-3-2:2014; EN61000-3-3:2013; EN55024:2010+A1:2015

LVD

EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013

Other

Cooling

Free air

Lifespan

20000hrs

Dimensions (L*W*H)

110*78*38mm

Weight

250g

Applications

DC Switching Power Supply 72W 12V 6A -01 (5)
